For compatibility with older Host implementations, the Equipment allows the following alternative form
for this message, using an array format:
S2F23 W * H->E
<L [5]
<U4 TRID> * Trace ID
<A ‘hhmmss’> * DSPER - Data Sample Period
<U4 TOTSMP> * Total Number of Samples
<U4 REPGSZ> * Reporting Group Size
<U4 SVID SVID ...> * Status Variable ID array
> .
4.2.23 S2F24 - Trace Initialize Acknowledge
S2F24 * H<-E
<B [1] TIAACK> . * TIAACK - Trace Init. Ack. Code
Table 4-5 Trace Initialize Acknowledge
TIAACK Description
0x00 Normal. Everything correct.
0x03 Invalid period. DSPER is incorrect. The
Equipment does not start the trace.
The Equipment does not signal an error if a Host error in S2F23 causes S6F1 to be multi-block. Instead,
this Equipment sends multi-block S6F1 as requested by the Host.
This Equipment does not signal an error if the Host initiates more than four (4) simultaneous traces. The
maximum number of traces supported depends on the size of the trace data, but is always at least 4.
Equipment-to-Host Messages 4-15
