Item Part Description Quantity Note
25 973 529
SConnector, male, barbed, M5, ss
1
26 982 746
SScrew, socket head, 4-40 x 1.00 in.
2
27 226 278
SValve, 3-way, solenoid, 24 Vdc, 120 psi
1
28 234 154
SPlug, M5, ss
1
29 234 149
SKey, hex, 1.5 mm
1 D
30 234 150
SKey, hex, 0.050 in.
1 D
31 234 151
SKey, hex,
7
/
64
in.
1 D
32 129 612
SKey, hex,
3
/
32
in.
1 D
33 272 821
STool, removal, retaining ring
1 E, F
34 226 274
SWrench, torque, 19 lb-in.,
1
/
2
hex
1 G
35 124 520
SDriver, screw, adjustable
1 E, F
36 115 059
STool, ring and seal, insertion
1 E, F
37 274 973
STool, piston, insertion
1 E, F
38 145 468
SWrench, spanner
1 E, F
39 226 302
STool, ring and seal insertion
1
NS 245 773
SConductive grease
1 E
NS 901 935
SWire, cleaning, 0.003 dia
1 H
NS 901 922
SWire, cleaning, 0.007 dia
1 H
NS 901 923
SWire, cleaning, 0.011 dia
1 H
NS 901 924
SWire, cleaning, 0.014 dia
1 H
NS 901 916
SPin vise
1 H
NS 901 905
SNozzle brush
1 E
NS 901 911
SWrench, module adjusting
2 D
NS - - - - - -
SCase, dispenser
1
NS 602 209
SCase, nozzle
1
NS 234 148
SCotton swab
AR E
NOTED:These tools are located in the Dispenser Assembly Wrench box.
E:These tools are located in the Dispenser Assembly and Cleaning box.
F:See Figure 11.
G:Order the torque wrench separately from your Nordson representative.
H:These tools are located in the Nozzle Cleaning box.
AR: As Required
NS: Not Shown
