See Figure 10.
Item Part Description Quantity Note
— 226 300 Applicator, adhesive, AccuJet 1 A
1 226 289
SMicro-adjustment, with lock
1
2 982 745
SScrew, set, preload
2
3 226 276
SScrew, preload
1
4 145 461
SNut, locking
1
5 234 170
SCap, end
1
6 981 029
SScrew, fillister, 6-32 x 0.500 in.
2
7 234 299
SSpring, compression
1
8 226 277
SRetainer, spring
1
9 168 833
SNut, seal, lock
1
10 940 090
SO-ring, Viton, 0.218 x 0.344 x 0.063 in.
1
11 115 055
SPiston, air
1
12 270 511
SNeedle and seat, 0.093 ball, 0.060 orifice
1 A, C
13 982 747
SScrew, socket head, 6-32 x 1.750 in.
2
14 - - - - - -
SNozzle
1 B
15 226 251
SCable
1
16 234 136
SHeater, extension
1
17 981 028
SScrew, fillister, 6-32 x 0.75 in.
2
18 719 082
SO-ring, Kalrez, 0.563 x 0.688 x 0.063 in.
1
19 940 139
SO-ring, Chemraz, 0.313 x 0.438 x 0.060 in.
1
20 955 055
SSeal, U-cup
2
21 226 279
SScrew, purge
1
22 234 168
SBody, lower
1
23 234 140
SConnector, leur, male, syringe
1
24 - - - - - -
SBody, upper
1
NOTEA:Dispenser part 249 927 is identical to dispenser part 226 300, except that it uses the needle and seat,
0.093 ball, .030 orifice part 270 512.
B:Refer to Nozzles to order optional nozzles.
C:Items are shipped as a matched set.
Continued on next page
