Disassembly (contd.)
1234002A
9
7
10
14
6
1
2
3
8
12
13
17
4
5
11
15
16
Fig. 3 Dispenser cleaning
1. Micro-adjustment cap
2. Preload screw
3. Locking nut
4. Lower body
5. Heater
6. Screw
7. Nozzle
8. Conductive grease application
9. Seat extension
10. O-ring (large)
11. O- ring (small)
12. U-cup seal
13. Needle
14. Screw
15. Purge screw
16. Syringe connector
17. Upper body
