User guide

AccuJet  Dispenser
15
 1998 Nordson Corporation
All rights reserved
107 142B
Issued 4/98
Manual 12-34
1234001A
1
2
4
3
5
11
10
9
67
8
Fig. 2 AccuJet dispenser
1. Solenoid valve connector
2. Syringe
3. Micro-adjustment assembly
4. Robot mounting plate
5. Mounting screws
6. Nozzle
7. Heater
8. Solenoid valve
9. Heater connector
10. Syringe connector
11. Upper body air fitting
