NOTE: Dispenser installation is dependent upon the workcell. Consult
your Nordson representative if more information is necessary.
See Figure 2.
1.Use the mounting screws (5) to install the dispenser on the
robotmounting plate (4). Tighten the screws securely.
2.Connect the solenoid valve connector (1) to the 24 volt timed-control
signal.
NOTE: The control signal must be able to maintain 18–24 Vdc when
the signal is on.
3.Connect the heater connector (9) to the temperature controller.
4.Connect the air line to the upper body air fitting (11).
3. Installation
