6.4 Bolt torque values
Bolt Torques [Nm]
Size
Screw connections in the strength
classes
Cap screws
Pipe and hose
connections
Threaded pin on
coupling
8.8 10.9 12.9
M4 3,2 5 6 - - -
M5 6,4 9 11 - - 2
M6 11 16 19 - - -
M8 27 39 46 5 - 10
M10 53 78 91 8 - 17
M12 92 135 155 27 - 40
M16 230 335 390 - - -
M20 460 660 770 - - -
M24 790 1150 1300 80 - -
M30 1600 2250 2650 170 - -
M36 2780 3910 4710 - - -
M42 4470 6290 7540 - - -
M48 6140 8640 16610 - - -
M56 9840 13850 24130 - - -
G ½ - - - - 20 -
G ¾ - - - - 20 -
G 1 - - - 20 20 -
G1¼ - - - 20 20 -
