Installation Manual

Testing Signal Strength at Fixed Wireless Terminal Site
Fixed Wireless Terminal Description and Installation
4/98
2-6
Assemble the unit
Remove the FWT from the box and attach the antenna to the connector
on the rear panel.
Connect the wall plug to the FWT and plug it in at the wall. (Optionally,
connect a charged battery in the battery compartment; this will allow
more freedom of movement when locating the best signal strength.)
Plug a touch–tone telephone into the RJ–11 connector on the rear panel.
Figure 4: FWT Signal Strength Indicator
SERVICE LED
. . . continued on next page
