Fixed Wireless Terminal Description and Installation
Specifications
The physical, electrical, and environmental specifications for the FWT
are as follows:
Dimensions:
– LxWxH: 165 mm x 215 mm x 61 mm (6.5 in. x 8.46 in. x 2.4 in.)
– Weight with battery: 1.4 kg (3.14 lbs)
– Weight without battery: .76 kg (1.7 lbs)
Radio frequency
800 MHz:
– Transmit: 824 – 849 MHz
– Receive: 869 – 894 MHz
1.9 GHz:
– Transmit: 1930 to 1990 MHz
– Receive: 1850 to 1910 MHz
Power source range
– Voltage: 120/240 VAC
– Frequency: 50/60 Hz
Operating power
– 12 VDC
Operating Temperature
–0
°
to +50
°
C (+32
°
to +122
°
F)
AC wall cube options
Consult your local power company for the proper plug and
input voltage rating.
NOTE
A variety of wall cubes is available to match the local power service.
See Figure 6 for AC–DC wall cube configurations.
Battery power
– 12 VDC
– Charges while unit is operating on AC power
– 8–hour standby operation (typical)
– 1–hour voice operation (typical)
– Battery removal has no effect on the unit while operating from AC
power source
