SC4812ET BTS Optimization/ATP — CDMA LMF

Table 3-10: Downloading and linking master–bts–cdma directory files for device loads

Step Action

NOTE

File naming conventions for all processor boards and applicable files for each are listed below.

Rename files using the

mv UNIX command as required:

Device File Name(s)

 GLI <version>–gliboot.hex & gli.dds

 BBX <version>–bbxboot.hex & bbx.dds

 BDC <version>–bdcboot.hex & bdc.dds

 MCC <version>–mccboot.hex.0501 & mcc.dds.0501

 CSM <version>–csmboot.hex & csm.dds

 TSU tsuboot.hex

4 Insert the first 3.5 inch floppy diskette. Verify disk is loaded with the proper BTS files/versions by

typing the following at the

(lmf): prompt:

seedisk <cr>

5 To load the BTS files from the disk into the appropriate directory, enter the following at the (lmf):

prompt:

fromdisk <cr>

6 If files are compressed, use the uncompress *.Z command to unpack files. Rename files to match

the naming conventions listed above if required.

7 Repeat Steps 4 and 5 for each diskette that is a part of this load.

NOTE

All older versions of files (and links to files) in the bts–master–cdma bts–<bts#> subdirectories

must be removed before beginning this procedure.

8 Create softlinks to the device load and data load files in the bts–master–cdma directory using the

following UNIX commands:

ln –s /usr/lmf/bts–master–cdma/*.hex /usr/lmf/bts–<bts#>/

ln –s /usr/lmf/bts–master–cdma/*.hex.* /usr/lmf/bts–<bts#>/

ln –s /usr/lmf/bts–master–cdma/*.dds /usr/lmf/bts–<bts#>/

ln –s /usr/lmf/bts–master–cdma/*.dds.* /usr/lmf/bts–<bts#>/

NOTE

You may need to specify specific file names in the command instead of using the * ”wildcard”

character in order to link multiple versions of files in the same subdirectory. Using *.* will link ALL

files in the directory.
