Table H-3: SC 4812ET Series 6-Sector Duplexed Directional Coupler to RFDS Cabling Table
DRDC Label Directional Coupler Port Cobra RFDS Port
ASU 1 – FWD (six pack MCX)
1A BTS Sector 1 Main BTS ASU1–FWD BTS–1
1B BTS Sector 1 Diversity BTS ASU1–FWD BTS–2
2A BTS Sector 2 Main BTS ASU1–FWD BTS–3
2B BTS Sector 2 Diversity BTS ASU1–FWD BTS–4
3A BTS Sector 3 Main BTS ASU1–FWD BTS–5
3B BTS Sector 3 Diversity BTS ASU1–FWD BTS–6
ASU 2 – FWD (six pack MCX)
4A BTS Sector 4 Main BTS ASU2–FWD BTS–1
4B BTS Sector 4 Diversity BTS ASU2–FWD BTS–2
5A BTS Sector 5 Main BTS ASU2–FWD BTS–3
5B BTS Sector 5 Diversity BTS ASU2–FWD BTS–4
6A BTS Sector 6 Main BTS ASU2–FWD BTS–5
6B BTS Sector 6 Diversity BTS ASU2–FWD BTS–6
ASU 1 – REF (six pack MCX)
1A ANT Sector 1 Main ANT ASU1–REF ANT–1
1B ANT Sector 1 Diversity ANT ASU1–REF ANT–2
2A ANT Sector 2 Main ANT ASU1–REF ANT–3
2B ANT Sector 2 Diversity ANT ASU1–REF ANT–4
3A ANT Sector 3 Main ANT ASU1–REF ANT–5
3B ANT Sector 3 Diversity ANT ASU1–REF ANT–6
ASU 2 – REF (six pack MCX)
4A ANT Sector 4 Main ANT ASU2–REF ANT–1
4B ANT Sector 4 Diversity ANT ASU2–REF ANT–2
5A ANT Sector 5 Main ANT ASU2–REF ANT–3
5B ANT Sector 5 Diversity ANT ASU2–REF ANT–4
6A ANT Sector 6 Main ANT ASU2–REF ANT–5
6B ANT Sector 6 Diversity ANT ASU2–REF ANT–6
