Downloading ROM Code with the LMF continued
SC4812ET BTS Optimization/ATP CDMA LMF
Jan 2002
J-2
The Release level of the ROM code to be downloaded
must be the one specified for the software release installed
in the BSS. The release level of the ROM code resident in
the other devices in the BTS must also be correct for the
BSS software release being used. ROM code must not be
downloaded to a frame loaded with code for a BSS
software release with which it is not compatible.
This procedure should only be used to upgrade
replacement devices for a BTS. It should NOT be used to
upgrade all devices in a BTS. If a BTS is to be upgraded
from R15.x to R16.0, the upgrade should be done by the
OMCR using the DownLoad Manager.
CAUTION
Table J-1: Download ROM and RAM Code to Devices
Step Action
1
Click on the device to be loaded.
NOTE
More than one device of the same type can be selected for download by either clicking on each one to
be downloaded or from the BTS menu bar Select pulldown menu, select the device item that applies.
Where: device = the type of device to be loaded (BBX, CSM, MCC)
2 From the BTS menu bar Device pulldown menu, select Status.
A status report window will appear.
3
Make a note of the number in the HW Bin Type column.
NOTE
HW Bin Type is the Hardware Binary Type for the device. This code is used as the last four digits in
the filename of a devices binary ROM code file. Using this part of the filename, the ROM code file
can be matched to the device in which it is to be loaded.
4 Click OK to close the status window.
5 Click on the device to be loaded.
6
* IMPORTANT
The LMF will not automatically select ROM code files for download. ROM code files must be
selected manually.
From the BTS menu bar Device pulldown menus, select Download > Code Manual.
A file selection window will appear.
7 Doubleclick on the version folder with the desired version number for the ROM code file (for
example 2.16.0.x).
8 Doubleclick the Code folder.
A list of ROM and RAM code files will be displayed.
. . . continued on next page
