User Manual

CDMA 2000 Test Equipment Preparation continued
Jan 2002
I-11
SC4812ET BTS Optimization/ATP CDMA LMF
Figure I-7: Setting Advantest R3267 GPIB Address
o
n
REMOTE
LED
LCL Key
CONFIG
Key
Softkey Lable
Display Area
Softkey
Buttons
Keypad BS
Key
ENTR
Key
Advantest R3562 Signal
Generator GPIB Address
Set the GPIB ADDRESS switch on the rear of the Advantest R3562
signal generator to address 1 as shown in Figure I-8.
Figure I-8: Advantest R3562 GPIB Address Switch Setting
12345678
54321
GPIP ADDRESS
1
0
GPIB Address set to 1
I
