GPIB Addresses – continued
SC4812ET BTS Optimization/ATP — CDMA LMF
Jan 2002
I-4
HP8935 Test Set GPIB
Address
Follow the procedure in Table I-4 to verify and, if necessary, change the
HP8935 GPIB address.
This procedure assumes that the test equipment is set up
and ready for testing.
NOTE
Table I-4: Verify and/or Change HP8935 GPIB Address
Step Action
* IMPORTANT
The HP I/O configuration MUST be set to Talk & Listen, or NO device on the GPIB bus will be
accessible. (Consult test equipment OEM documentation for additional information as required.)
1 To verify that the GPIB addresses are set correctly, press Shift and LOCAL on the HP8935 (see
Figure I-3). The current HP–IB address is displayed at the top of the screen.
NOTE
HP–IB is the same as GPIB.
2 If the current GPIB address is not set to 18, perform the following to change it:
– Press Shift and Inst Config.
– Turn the Cursor Control knob to move the cursor to the HP–IB Adrs field.
– Press the Cursor Control knob to select the field.
– Turn the Cursor Control knob as required to change the address to 18.
– Press the Cursor Control knob to set the address.
3
Press Preset to return to normal operation.
