User Manual

GPIB Addresses
Jan 2002
I-1
SC4812ET BTS Optimization/ATP CDMA LMF
Introduction
Use the procedures in this appendix to verify and/or change the GPIB
addresses of the applicable test equipment.
HP437 Power Meter GPIB
Address
Follow the steps in Table I-1 to verify and, if necessary, change the
HP437 GPIB address.
This procedure assumes that the test equipment is set up
and ready for testing.
NOTE
Table I-1: Verify and/or Change HP437 Power Meter GPIB Address
Step Action
1 Press Shift and PRESET (see Figure I-1).
2 Use the arrow key to navigate to HPIB ADRS and press ENTER.
The HPIB address is displayed.
NOTE
HPIB is the same as GPIB.
3 If the current GPIB address is not set to 13, perform the following to change it:
Use the arrow keys to change the HPIB ADRS to 13.
Press ENTER to set the address.
4 Press Shift and ENTER to return to a standard configuration.
Figure I-1: HP437 Power Meter
ENTER
PRESET
SHIFT (BLUE) PUSHBUTTON
ACCESSES FUNCTION AND
DATA ENTRY KEYS IDENTIFIED
WITH LIGHT BLUE TEXT ON
THE FRONT PANEL ABOVE
THE BUTTONS
FW00308REF
