User's Manual

Pinging the Processors continued
PRELIMINARY
1X SCt4812ET Lite BTS Optimization/ATP
08/01/2001
3-30
Table 3-12: Pinging the Processors
Step Action
13 If ping was unsuccessful after restarting the CDMA LMF computer, press the MGLI front panel reset
pushbutton and perform steps 6 through 9 again.
14
NOTE
Refer to Table 6-1 if ping was unsuccessful after resetting the MGLI.
15 After the BTS has been successfully pinged, be sure the 50 termination was replaced on the BTS
frame LAN B IN connector in the power entry compartment (Figure 3-12). Disconnect the LMF cable
from the LAN shelf LAN A connector, and connect it to LAN B (righthand connector) using a
BNCfemaletoBNCfemale adapter (refer to Figure 3-10).
16 In the power entry compartment, remove the 50 termination on the BTS frame LAN A IN connector.
17 Repeat steps 5 through 8 using LAN B.
18 After the BTS has been successfully pinged on the secondary LAN, replace the 50 termination on
the frame LAN A IN connector in the power entry compartment.
19 Disconnect the LMF cable from the LAN shelf LAN B and connect it to LAN A using a
BNC-female-to-BNC-female adapter.
20 Remove and replace the 50 termination on the LAN B IN connector to force the MGLI to switch to
primary LAN A.
21 Repeat steps 5 through 8 to ensure proper primary LAN operation.
3
