Specification

[ Di700A Specifications ]
(*1) Not compatible with Nissin Battery Magazine BM-01
(*2) Not correspond to the wireless optical TTL master. Can be set as A/B/C group
(*3) SD: Pre-flash, SF:Flash
Signal by Air 1
Type
for Canon/ Nikon and Sony Digital SLR cameras
Guide no. (at ISO 100 in m)
GN54 (at 200mm zoom head position)
GN48 (at 105mm zoom head position)
GN28 (at 35mm zoom head position)
Focal length coverage
24 - 200mm (16mm when using build-in wide panel)
Power Source
Four size-AA batteries
Battery loading system
Quick loading – Battery Magazine (BM-02) (*1)
Recycling Time
0.1 - 4 sec
Number of flashes (Approx.)
200 - 1500 flashes
Flash duration
1/800 - 1/30,000 Sec
Color Temperature
5,600K
Exposure control
E-TTL II / E-TTL (Canon), i-TTL (Nikon) and ADI/P-TTL (Sony)
Wireless Mode
2.4GHz Wireless TTL Slave: radio transmission (NAS
specifications).
Optical Wireless TTL Slave (only correspond to the same brand of
camera systems) (*2)
Optical slave mode (*3) (SD / SF mode)
EV compensation on flash
-2 to +2 EV in increments of 1/2 EV
Bounce position
Up: 90°, Down: 7°, Left: 180°, Right 180° (with flash head tilting /
rotating lock release button)
Flash exposure control
1
st
- Curtain synchronization, 2
nd
- Curtain synchronization, High-
speed synchronization, Red-eye reduction, Slow synchronization
(only available on Nikon Model), FE / FV Lock (set on camera)
AF-assist beam effective range
0.7 – 6m/ 2.3 – 19.7 feet
Operation panel
LED Color panel, select dial
External service ports
External power source socket, standard and 3.5mm PC sync
terminal
Radio specifications
2.4GHz ISM band (Obtaining technical standards conformity
certification)
Accessories
Soft case, flash stand (with screw)
Channel
8 channels (Channel setting in Air 1)
Dimensions
140(H) x 75(W) x 115(D) mm/ 5.5 (H) x 3(W) x 4.5(D) inches
Weight
380g/ 13.4oz (without batteries)
