PS-470/1 仕様
Specifications
Optical Fiber Camera Adaptor PS-470/1
Output
Time Code
BNC x1
BNC x1: HD-SDI
BNC x1: 1Vp-p, 75Ω, self-detecting, dual purpose Genlock/Teleprompter output,
composite or HD-Y (down grade compared to standard HD signal)
Return
Genlock (Prompter)
DC out
Total 75W ※1
XLR 4pin(female) x1 : DC 15V 3.5A (Maximum 15V, 3.5A)
V-mount Adaptor x1 : DC 15V 3.5A (Maximum 15V, 3.5A)
Monitor
Mini 6pin(female) x1: composite video, TALLY and DC power 13.5V 150mA (Maximum 13.7V)
for LVM-89W Monitor
Input
DC In
V-mount Holder x1 : 15V ※1
HD/SD- SDI HD-SDI :1.485Gbps,1.485/1.001Gbps(reclock)
SD-SDI :143Mbps,177Mbps, 270Mbpd,360Mbps, 540Mbps(reclock)
Incom
Incom XLR 4pin(male) x2
Tally
Tally indicator x2 LED (Main panel) x1 and Tally Lamp ( Connector panel, ON/OFF Selectable )x1
Remote
Remote 8pin or 10-pin ※2
LANC Stereo mini-jack Φ2.5mm
Optical fiber connection
Socket LEMO P/N: EDW.3K93C.TLC
Maximum distance 2km with power supplied from PS570
General
Weight approx. 1.8kg
Dimensions 180x169x91 mm (WxHxD)
Power requirement DC 15V 20W MAX (when supplied via DC IN)
Power consumption DC operation Maximum: applox. 20W
0℃ to 40℃ (+32 to 104F)
-20℃ to 60℃ (-4 to 140F)
Operating temperature
Storage temperature
※1 : DC output are available only when the power is supplied from PS-570 via an optical fiber cable.
Features, design and specifications are subject to change without notice.
※2 : 8-pin for SONY RM-B750 or RM-B150. 10-pin for Pnasonic AG-EC4G or AJ-RC10G
デザイン, 仕様は、予告なく変更することがあります。
Tally out
BNC x1: TALLY OUT ON
= 5 V
