Instruction User Manual

28
Connect the REF. OUT connector to a camera with a BNC cable.
to
camera
REF.
OUT
(BNC)
1
2
Reference (GENLOCK) signal connection
Connect a reference (GENLOCK) signal from an reference (GENLOCK) signal generator to the REF. IN
connector with a BNC cable.
from
reference (GENLOCK)
signal generator
REF. IN (BNC)
AC IN
100/200V(85-240V)
LANC
TALLY
OPT
REF. INHD/SDI OUT 1
PROMPTER/
IN OUT
VIDEO OUT
HD-Y/VIDEO
OUT
RET1 IN
TC IN
TC OUT
REMOTE
HD/SDI IN1 HD/SDI OUT 2
HD-Y/VIDEO
REF. VIDEO IN
RET2 IN
HD-Y/VIDEO
HD/SDI IN2
RET RET
INTERCOM
12 1
2
MADE IN JAPAN
AUDIO IN
CA
AUDIO OUT
DC IN
12V(12V-18V)
PGM
2W PROD
2W ENG
INTERCOM 4W
Reference (GENLOCK) signal
Reference (GENLOCK) signal
Optical Fiber Camera Adaptor LS-700/Optical Fiber Base Station LS-800
LS-700/LS-800
LS-700
LS-800
(connector panel)
IF OUT
RET
HD-SDI
OUT2
HD-SDI
IN2
REF.
OUT
HD-SDI
IN1
RET
HD-SDI
OUT1
LANC
TC
IN
TC
OUT
DC OUT 15V (MAX3A)
▲
OFF
H
L
