Instruction User Manual

23
RET
HD-SDI
OUT 1
or
RET
HD-SDI
OUT 2
HD/SD-SDI monitor
SDI(HD/SD) IN
HD/SD-SDI return signal monitoring connection
Connect the RET HD-SDI OUT 1 or 2 connector of LS-700 to the SDI(HD/SD) input connector of a
HD/SD-SDI monitor with a BNC cable.
1
2
3G/HD/SD-SDI signal
RET HD/SDI IN 1(BNC)
Connect the 3G/HD/SD-SDI return signal from a switcher to the RET HD/SDI IN 1/2 connector of
LS-800 with a BNC cable.
from
switcher,
etc.
RET HD/SDI IN 1
or RET HD/SDI IN 2
RET HD/SDI IN 2(BNC)
AC IN
100/200V(85-240V)
LANC
TALLY
OPT
REF. INHD/SDI OUT 1
PROMPTER/
IN OUT
VIDEO OUT
HD-Y/VIDEO
OUT
RET1 IN
TC IN
TC OUT
REMOTE
HD/SDI IN1 HD/SDI OUT 2
HD-Y/VIDEO
REF. VIDEO IN
RET2 IN
HD-Y/VIDEO
HD/SDI IN2
RET RET
INTERCOM
12 1
2
MADE IN JAPAN
AUDIO IN
CA
AUDIO OUT
DC IN
12V(12V-18V)
PGM
2W PROD
2W ENG
INTERCOM 4W
3G/HD/SD-SDI signal
LS-800
Optical Fiber Camera Adaptor LS-700/Optical Fiber Base Station LS-800
LS-700/LS-800
IF OUT
RET
HD-SDI
OUT2
HD-SDI
IN2
REF.
OUT
HD-SDI
IN1
RET
HD-SDI
OUT1
LANC
TC
IN
TC
OUT
DC OUT 15V (MAX3A)
▲
OFF
H
L
(connector panel)
LS-700
(PROTECH HD View Finder HDF-700)
