Technical specications
Parameter Units ATTIX 115-01 ATTIX 125-01
Voltage (50 - 60 Hz) V 230
Power rating kW 3
Power rating (EN 60335-2-69) kW 2,6
Max vacuum hPa
(2)
211
Maximum air ow rate (without hose and reductions) L/min’ 8100
Maximum air ow rate (with hose, length: 3 m,
diameter: 70 mm)
L/min’ 7500
Noise level (Lpf) (EN60335-2-69) dB(A) 75
Protection IP 43
Insulation Class I
Inlet (diameter) mm 70
Accessories allowed (diameter) mm 36
(3)
/ 50
Main lter surface m
2
1.95 2.1
Model Units ATTIX 115-01 / ATTIX 125-01
Container capacity L 100
Mass
(1)
kg 70
Dimensions
Figure 3
Model
ATTIX 115-01 / ATTIX 125-01
(L100)
A (mm) 795
B (mm) 600
C (mm) 1570
(1) Net weighth
(2) Pa = mbar
(3) Recommended use with only one motor running
■ Storage conditions:
T : -10°C ÷ +40°C
Humidity: 85%
■ Operating conditions:
Maximum altitude: 800 m
(Up to 2,000 m with reduced performances)
T : -10°C ÷ +40°C
Humidity: 85%
