User manual

C365
4
11/2010
ATTIX 115-01 / ATTIX 125-01
GB
Vacuum cleaner description
Optional kits
Please contact the manufacturer’s sales network for
information on optionals.
Instructions for installing the optional are included in the
conversion kit.
WARNING!
Use only supplied and authorized genuine spare parts.
Accessories
Various accessories are available; refer to the manufacturer’s
accessory catalogue.
WARNING!
Use only genuine accessories supplied and
authorized by the manufacturer.
Packing and unpacking
Dispose of the packing materials in compliance with the laws
in force.
Figure 2
Model
ATTIX 115-01 / ATTIX 125-01
(L100)
A (mm) 700
B (mm) 860
C (mm) 1750
Weight with packing (kg) 89
Vacuum Cleaner Parts and Labels
Figure 1
1. Identication plate which includes:
Code of the Model, Technical Specications (see table
on page 6), Serial No., EC Mark, Year of manufacture,
Nominal network voltage.
2. Dust container
3. Dust container release lever
4. Inlet
5. Outlet
6. Attention plate
Draws the operator’s attention to the fact that the lter
must only be shaken when the vacuum cleaner is turned
off (see also par. “Primary lter shaker”).
7. Plug for connecting the vacuum cleaner to an electrical
socket.
This vacuum cleaner creates a strong air ow which is drawn
in through the inlet (4 - Fig. 1) and blown out through the
outlet (5 - Fig. 1).
Before turning on the vacuum cleaner, t the vacuum hose
into the inlet and then t the required tool on to the end part
(refer to the manufacturer’s accessory catalogue or Service
Centre).
The diameters of the authorised hoses are given in the
technical specications table.
The vacuum cleaner is equipped with a primary lter which
enables it to be used for the majority of applications.
Besides the primary lter, which retains the most common
types of dust, the vacuum cleaner can be tted with a
secondary lter (absolute H class) with a higher ltering
capacity for ne dusts and dusts that are hazardous to health.
