Installation Instructions

Installation Instructions:
Quick Reference Checklist
1. Cut tube square w/tubing cutter or fine tooth saw.
2. Deburr and ream inside & outside of tube end. Make
sure surface is smooth with no burrs or sharp edges.
3. Check fitting/valve for O-ring seal.
4. Mark insertion depth on tube and insert tube (slightly
turning) into fitting. (Do NOT use any lubricants).
5. Safely press fitting/valve with proper tools & jaws.
6. Double-check joint to confirm that each fitting/valve
has been aligned correctly and fully crimped.
7. Test system in accordance withNIBCO installation
instructions and in accordance with engineering
jurisdiction piping codes. System rated @ 200 PSIG
-20 ºF to 250 ºF.
Caution:
*Do NOT press fittings or valves within 12” of annealed/brazed tubing.
*Do NOT braze or solder within 12” of press fittings/valves. If absolutely
necessary, take proper precautions to protect the EPDM seal from any heat
source. For example, wrap with a cool wet cloth or rag.
