Specification

Job/Customer _________________________________ Date ____________________ Contractor _____________________________
Model Specified _______________________________ Qty _____________________ Approved By ___________________________
Designer/Engineer _____________________________ Date ____________________ Contractor’s PO# ________________________
Submitted by _________________________________ Date ____________________ Other _________________________________
THIS SPACE FOR DESIGNER/ENGINEER APPROVAL
*Dimensions for reference only.
Temperature locking handle
° °
° °
Hot Inlet Temperature Range
120 - 185°F (49 - 85°C)
Cold Inlet Temperature Range
39 - 80°F (4 - 27°C)
Outlet Temperature Stability
1
± 5°F (3°C)
Working Pressure Range
30 - 150 psi (2 - 10 bar)
Minimum Temperature Differential
20°F (11°C)
Between Hot Supply and Mixed Outlet
2
Maximum Inlet Pressure Ratio
3
2:1
Minimum Flow Rate
for optimal performance
0.5 gpm (2 L/min)
C
v
2.5
ASSE 1070, ASSE 1017
CSA B125.3
NSF/ANSI 61, NSF/ANSI 372
