User's Manual

Nexxt Solutions - ACRUX - Wireless N Gigabit Router
18
Check the connection by executing the following
steps:
Is the connection between your PC and the router
correct?
Note:
The 1/2/3/4 LEDs of LAN ports on the router
which your computer is linked to, and the LEDs on
your PC’s adapter should be lit.
Is the TCP/IP configuration for your PC correct?
Note:
If the router’s IP address is 192.168.0.1, your
PC’s IP address must be within 192.168.0.2 ~
192.168. 0.254 range.
To access the configuration utility, open a
web-browser and type in the default address
http://192.168.0.1 in the address field of the
page.
Within seconds, a login window will appear, similar
to the one shown in Figure 3-4. Enter admin for
the User Name and Password, both in lower case
letters. Then click the OK button or press the Enter
to continue.
3.2 Quick Installation Guide
The configuration and management of the Wireless
N Gigabit Router is made simple through a
Web-based (Internet Explorer or Netscape
®
Navigator) utility. The Web-based utility can be used
on any Windows, Macintosh or UNIX OS with a Web
browser.
1.
1.
2.
Figure 3-3 Login the router
