8.5.1 Program Function Commands
The following commands are relevant to the currently select Program Phase. Note: During a Pumping
Program’s operation, the currently selected Phase can change automatically.
PHASE NUMBER
PHN [ <phase data> ]
Set/query currently selected Program Phase:
Set:
Currently selected Phase is set to <phase data>. Previous Phase is stored in non-volatile memory and
the requested Phase is recalled from the non-volatile memory. Set is only valid if the Pumping
Program is not operating.
Query response:
<phase data> Currently selected Phase
PUMPING PROGRAM FUNCTION
FUN [ <phase function> ]
Set/query the Pumping Program Phase’s function.
This command is relevant to the currently selected Phase. Set is only valid if the Pumping Program is
not operating
For a more detailed description of Program commands, see sec. 7.3, Program Function Descriptions.
<phase function> =>
Rate Data Functions
When a Phase’s function is set to a “Rate Data Function”, use the ‘RAT’, ‘VOL’, and ‘DIR’
commands to setup the pumping parameters for the current phase.
RAT Pumping rate.
INC Increment rate.
DEC Decrement rate.
Non-Rate Control Functions
STP Stop pump.
PAS <number data> Pauses pumping for ‘nn’ seconds, or until trigger if 0.
PAS <n.n> Pauses pumping for 'n.n' seconds.
LOP <count data> Loop to previous loop start ‘nn’ times.
LPS Loop starting Phase.
LPE Loop end Phase.
JMP <phase data> Jump to Program Phase.
Conditional Functions
IF <phase data> If Program input TTL pin low, jump to Phase.
EVN <phase data> Set event trigger trap.
EVS <phase data> Set event square wave trigger trap.
EPL <expansion pin> Pause and wait for expansion pin event edge or level.
EPE <expansion pin> Pause and wait for expansion pin event edge.
EVE <expansion pin> Re-direct event trigger trap to expansion pin.
EVR Event trigger trap reset.
TTL Logic and Other Functions
OUT <TTL level> Set programmable output pin.
OE0 <expansion pin> Set expansion pin to 0 (low level).
OE1 <expansion pin> Set expansion pin to 1 (high level).
BEP Sound short beep.
PUMPING RATE
