Instructions

G H
Break out!
Cut!
K
I J
Press
down!
Snap in
Hang up!
Note for Right-Angle Version
Working steps same as above.
Except:
Step B - References
Step G - The cable outlet must not be
interrupted.
to step B and bend
the reinforcement metal right
angle below.
1.
2.
Cover assembly
Connect the screen
Assembly the adapter
Grounding option
Assembly the chassis
Please fix the cable additionally.Attention: Before assembly secure the housing in the device.
B
G
Insert until it
snaps in
Insert contact only if screen should
be connected to front panel
L
Finish
Draft. Nr.: BDA 188 Update: 13.08.2009/ 3102M1561
II
Data subject to change without prior notice. 2009 NEUTRIK . ALL RIGHTS RESERVED.©
®
ASSEMBLY INSTRUCTION NE8FDY-C6
