Instructions

40 mm

Twist the

screen

8-7

4-5

6-3

2-1

8-7

4-5

6-3

2-1

S-FTP SF-UTP F-UTP

8-9 mm

C D

1. 2. 3. 4. 5.

2. Trimming!

1. Position the

cable!

Cable preparation

Shielding

Cable pairs separation Cable mount

Position wires acc. label

Cable tie

ASSEMBLY INSTRUCTION

NE8FDY-C6

etherCON Receptacle

Page 1

Fix wires

PAGE 1
ASSEMBLY INSTRUCTION NE8FDY-C6 | etherCON Receptacle A Cable preparation 8-7 2-1 4-5 6-3 40 mm Twist the screen 1. 2. 3. 4. 5. B Shielding S-FTP C SF-UTP Cable pairs separation F-UTP D Cable mount 6-3 2-1 4-5 Cable tie E Position wires acc. label 1. Position the cable! imm 2.
PAGE 2
ASSEMBLY INSTRUCTION I NE8FDY-C6 H Connect the screen G Cover assembly 2. 1. Break out! Hang up! I J Assembly the adapter Grounding option Insert contact only if screen should be connected to front panel Insert until it snaps in K Cut! L Assembly the chassis Finish Press down! Snap in Attention: Before assembly secure the housing in the device. Please fix the cable additionally. Note for Right-Angle Version Working steps same as above.
