Installation Instructions

NX-584 Home Automation
8
Segment 2:
DATA ENABLES TRANSITION
1
System Status Message
2
X-10 Message Received
3
Log Event Message
4
Keypad Message Received
5 - 8
Reserved
LOCATION 3 PROGRAMMING THE COMMAND / REQUEST ENABLES
(4 segments of feature selection data) The NX-584 has the ability to perform a variety of commands
asked of it by the home automation system. For example, it is possible to allow arming and disarming
of the security system, programming of the security system, or bypassing of zones by the home
automation system. Location 3 is used to select which commands, if any, you wish the home
automation system to have access. Consult the home automation application information and enable
the appropriate commands for your application. CAUTION: IT IS IMPORTANT TO UNDERSTAND
THE CAPABILITES OF THE HOME AUTOMATION SYSTEM TO AVOID COMPROMISING THE
SECURITY OF YOUR SYSTEM WHEN PROGRAMMING THIS LOCATION.
DATA SUPPORTED REQUEST / COMMAND
1
Reserved
2
Interface Configuration Request
3
Reserved
4
Zone Name Request
5
Zone Status Request
6
Zones Snapshot Request
7
Partition Status Request
8
Partitions Snapshot Request
Segment 2:
DATA SUPPORTED REQUEST / COMMAND
1
System Status Request
2
Send X-10 Message
3
Log Event Request
4
Send Keypad Text Message
5
Keypad Terminal Mode Request
6 - 8
Reserved
