Numerical Data: Numerical data is programmed by using the numeric keys of the system keypad to
enter a number from 0-255. To view the data in a location, a binary process is used. With this
process, the LED’s for zones 1 through 8 are utilized, and the numeric equivalents of their illuminated
LED’s are added together to determine the data in a programming location. The numeric equivalents
of these LED’s are as follows:
Zone 1 LED = 1 Zone 3 LED = 4 Zone 5 LED = 16 Zone 7 LED = 64
Zone 2 LED = 2 Zone 4 LED = 8 Zone 6 LED = 32 Zone 8 LED = 128
Example: If the numerical data to be programmed in a location is "66", press [6]-[6] on the keypad.
The LED’s for Zone 2 and Zone 7 will become illuminated indicating 66 is in that location (2 + 64 =
66). Once the data is programmed, press the [r] key to enter the data and advance to the next
segment of that location. After the last segment of a location is programmed, pressing the [r] key will
exit that location, turn the "Ready" LED off and the "Armed" LED on. As before, you are now ready to
enter another programming location. If an attempt is made to program a number too large for a
particular segment, the keypad sounder will emit a triple beep, indicating an error, and remain in that
segment awaiting a valid entry.
Feature Selection Data: Feature selection data will display the current condition (on or off) of eight
features associated with the programming location and segment selected. Pressing a button on the
touchpad (1 through 8) that corresponds to the "feature number" within a segment will toggle (on/off)
that feature. Pressing any numeric key between [1] and [8] for selection of a feature will make the
corresponding LED illuminate (feature ON). Press the number again, and the LED will extinguish
(feature OFF). You will see that numerous features can be selected from within one segment. For
instance, if all eight features of a segment are desired, pressing [1]-[2]-[3]-[4]-[5]-[6]-[7]-[8] will turn on
LED's 1 through 8 as you press the keys, indicating that those features are enabled.
LCD KEYPAD USERS NOTE:
The numbers of the enabled features will be displayed. However, the features not enabled will
display a hyphen (-). After the desired setting of features is selected for this segment, press the [r]
key. This will enter the data and automatically advance to the next segment of the location. When you
are in the last segment of a location and press the [r] to enter the data, you will exit that location.
This will now turn the "Ready" LED off and the "Armed" LED on. As before, you are now ready to
enter another programming location.
VIII.
LEDS INDICATORS
LED
INDICATIONS
DS1
Flashes for NetworX buss
DS3
Flashes for each valid packet received from host
DS4
Flashes for each packet transmitted to host
DS5
On when waiting for NetworX function to be completed
DS6
On when waiting for acknowledgement from host
