VI. PROGRAMMING THE MODULE
A. USING THE LED KEYPAD
To enter the Program Mode:
Enter [r]-[8] (all of the function key LEDs will begin to flash).
Enter the "Go To Program" code (default is [9]-[7]-[1]-[3]). If the code was valid, the
Service LED will flash, and the function LEDs will illuminate steady, indicating the device
to program should be entered.
Enter the address of the NX-584, which is [7] [2] followed by [#]. At this point, the Armed LED
will illuminate while it is waiting for a programming location to be entered.
Enter the desired programming location followed by the [#] key.
The Armed LED will begin to flash while a programming location is being entered. If this
is a valid location, the Armed LED will extinguish, the Ready LED will illuminate, and the
binary data for the first segment of this location will be shown on the zone LEDS.
If the desired location is the next sequential location, press the [POLICE] key.
If the previous location is desired press the [FIRE] key.
If the same location is desired press the [AUXILIARY] key.
To change the data, enter the data followed by [r].
The data will be entered, and the location will automatically increment to the next
segment. The data for that segment will be displayed. This procedure is repeated until
the last segment is reached.
To exit this location without changing the data, press the [#] key.
To review the data, repeat the above procedure, pressing the [r] key without entering data first.
Each time the [r] key is pressed, the next segment is displayed. After the last segment of a
location is programmed, pressing the [r] key will exit that location, turn the "Ready" LED off and
the "Armed" LED on. As before, you are now ready to enter another programming location. If an
attempt is made to program an invalid entry for a particular segment, the keypad sounder will
emit a triple error beep (beep, beep, beep) and remain in that segment awaiting a valid entry.
To exit the Program Mode, press the [Exit] key to exit this programming level. Pressing the
[Exit] key again will exit the Program Mode.
B. U
SING THE LCD KEYPAD
All steps required for programming are the same as the aforementioned LED keypad. The LCD
keypad display will prompt you for the data required. While in the programming mode, and not in a
location, the number in parenthesis is the location you were previously changing. For example, if the
display reads "Enter location, then # (2)", it is reminding you that location 2 was the last location you
programmed. In feature selection data, the numbers of the enabled features will be displayed. The
features not enabled will display a hyphen (-).
VII. PROGRAMMING DATA
Programming data is always one of two types. One type of data is numerical, which can values from
0 -15 or 0-255 depending on the segment size. The other type of data, feature selection data, is used
to turn features on or off. Use the following procedures with these two data types:
