LOC PG DESCRIPTION
“
1 = Program Data Request
“
2 = Program Data Command
“
3 = User Information Request with PIN
“
4 = User Information Request without PIN
“
5 = Set User Code Command with PIN
“
6 = Set User Code Command without PIN
“
7 = Set User Authorization Command with PIN
3 8
Segment 3
“
8 = Set User Authorization Command without
PIN
1 – 2 = Reserved
“
3 = Store Communication Event Command
“ 4 = Set Clock / Calendar Command
“
5 = Primary Keypad Function with PIN
“
6 = Primary Keypad Function without PIN
“ 7 = Secondary Keypad Function
Segment 4
“
8 = Zone Bypasss Toggle
4 9 LCD Keypad Address (1 segment)
KEYPAD
PART 1
PART 2
PART 3
PART 4
PART 5
PART 6
PART 7
PART 8
1
192
193
194
195
196
197
198
199
2 200 201 202 203 204 205 206 207
3 208 209 210 211 212 213 214 215
4 216 217 218 219 220 221 222 223
5 224 225 226 227 228 229 230 231
6 232 233 234 235 236 237 238 239
7 240 241 242 243 244 245 246 247
8 248 249 250 251 252 253 254 255
