X. PROGRAMMING WORKSHEETS
(Defaults are printed in bold italics text in a shaded area.)
LOC PG DESCRIPTION
Option Flags (1 segment)
Off = Binary “
Option 1
On = ASCII “
0 7
Options 2 - 8 Reserved
Baud Rate (1 segment)
“
0 = 600 Baud
“ 4 = 9600 (9.6K)
“
1 = 1200 (1.2K)
“
5 = 19200 (19.2K)
“
2 = 2400 (2.4K)
“
6 = 38400 (38.4K)
1 7
“
3 = 4800 (4.8K)
“
7 = 76800 (76.8K)
Enabling the Transitions (2 segments)
1 = Reserved
“ 2 = Interface Configuration
3 –4 = Reserved
“
5 = Zone Status Message
“
6 = Zones Snapshot Message
“ 7 = Partition Status Message
Segment 1
“
8 = Partitions Snapshot Message
“ 1 = System Status Message
“ 2 = X-10 Message Received
“
3 = Log Event Message
“
4 = Keypad Message Received
2 7
Segment 2
5 – 8 = Reserved
3 8 Programming the Command / Request Enables (4 segments)
1 = Reserved
“ 2 = Interface Configuration Request
3 = Reserved
“ 4 = Zone Name Request
“ 5 = Zone Status Request
“ 6 = Zones Snapshot Request
“ 7 = Partition Status Request
Segment 1
“ 8 = Partitions Snapshot Request
“ 1 = System Status Request
“ 2 = Send X-10 Message
“ 3 = Log Event Request
“ 4 = Send Keypad Text Message
“ 5 = Keypad Terminal Mode Request
Segment 2
6 – 8 = Reserved
