NX-584 HOME AUTOMATION MODULE

Installation Manual

These instructions do not purport to cover all details or variations in equipment nor to provide every possible contingency to be

met during installation, operation, and maintenance. If further information is desired or if particular problems arise that are not

covered sufficiently for the purchaser’s purpose, the matter should be referred to GE Interlogix, Gladewater, Texas, USA.

This document contains proprietary information of GE Interlogix, USA and is furnished to its customer solely to assist that

customer in the installation, testing, operations, and/or maintenance of the equipment described. This document shall not be

reproduced in whole or in part nor shall its contents be disclosed to any third party without the written approval of GE Interlogix.

Please refer to the current GE Interlogix product catalog for detailed warranty information.

TABLE OF CONTENTS

I. GENERAL DESCRIPTION .................................................................................................2

II. TERMINALS & PIN-OUT ....................................................................................................2

III. ENCLOSURE DIAGRAM....................................................................................................3

IV. WIRING DIAGRAM.............................................................................................................4

V. ENROLLING THE MODULE...............................................................................................4

VI. PROGRAMMING THE MODULE........................................................................................ 5

VII. PROGRAMMING DATA .....................................................................................................5

VIII. LEDS INDICATORS............................................................................................................6

IX. PROGRAMMING LOCATIONS ..........................................................................................7

X. PROGRAMMING WORKSHEETS....................................................................................10

XI. SPECIFICATIONS ............................................................................................................12

NetworX

Summary of content (12 pages)

PAGE 1
NX-584 HOME AUTOMATION MODULE Installation Manual These instructions do not purport to cover all details or variations in equipment nor to provide every possible contingency to be met during installation, operation, and maintenance. If further information is desired or if particular problems arise that are not covered sufficiently for the purchaser’s purpose, the matter should be referred to GE Interlogix, Gladewater, Texas, USA.
PAGE 2
I. GENERAL DESCRIPTION The NetworX NX-584 is a low cost add-on module that fits neatly into any NetworX family system enclosure and provides a standard RS-232 bi-directional DB-9 connector for connection to a home automation host system. A simple three-wire connection to the main control is all that is required to fully integrate this card into the system.
PAGE 3
Signal Name Direction NX------PC DB-9 Pin-out Jumper Pin Number Number A Position Cts* Txd Rts* Rxd Sig.Gnd. Unused → → ← ← ←→ -- J7 J8 J9 J10 --- 8** 2 8 2** 5 1,4,6,9 B Position 7 3** 7** 3 *Note: Rts and Cts signals are not currently supported **Note: Default jumper settings III. ENCLOSURE DIAGRAM Inside the can, several 2-holed insertion points have been constructed. This allows for either vertical or horizontal placement of the modules.
PAGE 4
IV. WIRING DIAGRAM LEDS Jumpers “A” Pos / “B” Pos J9 = 8 / 7* J7 = 8* / 7 J10 = 2* / 3 J8 = 2 / 3* * Default Position POS COM DATA CONNECT TO NX-8 TERMINALS “B” “A” ATTACH THE HOST TO THIS CONNECTOR “B” “A” LED for circuit operation only V. ENROLLING THE MODULE The NetworX control panels have the ability to automatically find and store in memory the presence of all keypads, zone expanders, wireless receivers, output modules, and any other device on the keypad buss.
PAGE 5
VI. PROGRAMMING THE MODULE A. USING THE LED KEYPAD B. To enter the Program Mode: Enter [r]-[8] (all of the function key LEDs will begin to flash). Enter the "Go To Program" code (default is [9]-[7]-[1]-[3]). If the code was valid, the Service LED will flash, and the function LEDs will illuminate steady, indicating the device to program should be entered. Enter the address of the NX-584, which is [7] [2] followed by [#].
PAGE 6
Numerical Data: Numerical data is programmed by using the numeric keys of the system keypad to enter a number from 0-255. To view the data in a location, a binary process is used. With this process, the LED’s for zones 1 through 8 are utilized, and the numeric equivalents of their illuminated LED’s are added together to determine the data in a programming location.
PAGE 7
IX. PROGRAMMING LOCATIONS LOCATION 0 PROGRAMMING THE OPTION FLAGS (1 segment of feature selection data) The NX-584 protocol can operate in one of two possible modes - binary or ASCII. Consult the home automation application information to determine the proper mode for your application and program it in Location 0. Option 1 LED 0ff = Binary Options 2 - 8 Reserved LOCATION 1 LED On = ASCII BAUD RATE TABLE (1 segment of numerical data) The NX-584 can operate on a number of different baud rates.
PAGE 8
Segment 2: DATA 1 2 3 4 5-8 LOCATION 3 ENABLES TRANSITION System Status Message X-10 Message Received Log Event Message Keypad Message Received Reserved PROGRAMMING THE COMMAND / REQUEST ENABLES (4 segments of feature selection data) The NX-584 has the ability to perform a variety of commands asked of it by the home automation system. For example, it is possible to allow arming and disarming of the security system, programming of the security system, or bypassing of zones by the home automation system.
PAGE 9
Segment 3: DATA 1 2 3 4 5 6 7 8 SUPPORTED REQUEST / COMMAND Program Data Request Program Data Command User Information Request with PIN User Information Request without PIN Set User Code Command with PIN Set User Code Command without PIN Set User Authorization Command with PIN Set User Authorization Command without PIN Segment 4: DATA 1 2 3 4 5 6 7 8 LOCATION 4 SUPPORTED REQUEST / COMMAND Reserved Reserved Store Communication Event Command Set Clock / Calendar Command Primary Keypad Function with PIN Pr
PAGE 10
PROGRAMMING WORKSHEETS X. (Defaults are printed in bold italics text in a shaded area.) LOC PG 0 7 DESCRIPTION Option Flags (1 segment) Option 1 Options 2 - 8 1 7 2 7 3 8 10 Off = Binary “ On = ASCII “ Reserved Baud Rate (1 segment) “ 0 = 600 Baud “ 4 = 9600 (9.6K) “ 1 = 1200 (1.2K) “ 5 = 19200 (19.2K) “ 2 = 2400 (2.4K) “ 6 = 38400 (38.4K) 3 = 4800 (4.8K) “ “ 7 = 76800 (76.
PAGE 11
LOC 3 PG 8 4 9 DESCRIPTION “ 1 = Program Data Request “ 2 = Program Data Command “ 3 = User Information Request with PIN “ 4 = User Information Request without PIN Segment 3 “ 5 = Set User Code Command with PIN “ 6 = Set User Code Command without PIN “ 7 = Set User Authorization Command with PIN 8 = Set User Authorization Command without “ PIN 1 – 2 = Reserved “ 3 = Store Communication Event Command “ 4 = Set Clock / Calendar Command Segment 4 “ 5 = Primary Keypad Function with PIN “ 6 = Primary Keypad
PAGE 12
XI. SPECIFICATIONS NX-584 DIMENSIONS 4 " Width x 3.25 " Length x 1 " Depth OPERATING POWER 12 VDC, Supplied from NX-8 or NX-320 AUXILIARY POWER Supplied by NX-8 or NX-320 NX-584 CURRENT DRAW 30 mA OPERATING TEMPERATURE 32 to 120 degrees F SHIPPING WEIGHT 1 lb.
