Web Interface
A user may control the connections of the VEEMUX using a Web Interface via any web browser (see page 1 for web supported
browsers). With the VEEMUX connected to a LAN through an Ethernet cable, a user can access the web interface controls inside
the VEEMUX.
FYI: To quickly locate a VEEMUX on the LAN and edit the IP address settings, use the Device Discovery Tool (page 25).
To access the web interface, type the current IP address into the address bar of the web browser.
Address
To open a SSL-encrypted connection, type:
Address
You will be prompted to accept a certificate. Accept the NTI certificate.
A "Welcome Page" will appear.
Figure 20- Web interface Welcome page
Enter the Password
Click on a link to the left to be prompted for a username and password.
Default User Name = Administrator
(upper case letter for "A" only)
Default Password = admin (lower
case letters only)
Note: The browser must be configured to accept
cookies in order for the user to successfully make use of
the web interface.
Figure 21- Web interface Login Prompt
As described on page 18, each link will enable different areas of control for the VEEMUX.
http://192.168.1.1
https://192.168.1.1
