Telnet Interface
The Telnet Interface enables the user to control the switch using telnet client through an Ethernet connection. The telnet server
listens on port 2000. To access the telnet interface, using the current IP address type the following in a command shell:
telnet 192.168.1.1 2000
The VEEMUX will prompt the user for a password. The user must enter the password followed by <Enter>.
The default factory password is "admin".
With a proper password sent the VEEMUX will respond with:
Password Successful
Connection Established
The following commands are now available:
Command Reply Description
H(elp) or
h(elp)
Displays the list of
commands
Help
<Ctrl>-<X>
(see note 4 below)
Good Bye.
Connection to host lost.
Quit telnet session
CS nn,mm *<CR> Connect one Output Port (nn) To one Input Port (mm)
CA nn *<CR> Connect All Outputs To Input
RO nn *<CR>mm<CR>
Read Connection For Output.
Returns the number of the input (mm) connected to output nn
CC nn *<CR>nn<CR>
Save Matrix Connections Into Memory Bank nn
nn should be between 00 and 09
RC nn *<CR>nn<CR>
Restore Matrix Connections From Memory Bank nn
nn should be between 00 and 09
CB nn *<CR>
Change baud rate of serial line, nn=12(00),24(00),48(00),96(00)
Factory default is 9,600.
RV 00 *<CR>string\0<CR> Read NTI Version String
RU *<CR>nn,mm<CR>
Read Unit Size
Returns the number of inputs(nn) and the number of outputs (mm)
CP
User is prompted to
introduce the password
twice
Change password
Notes:
1. The commands must be typed exactly as shown in the chart. The commands are case sensitive.
2. If a mistake is made, the user must backspace to the beginning and completely retype the command.
3. If a command is sent that the VEEMUX does not recognize or exceeds the configuration of the switch, the reply
"?" may be received. Check the command syntax and try again.
4. To quit the telnet session, press the keyboard keys <Ctrl><X> .
