User Manual

Introduction

General Description

Easily constructing your LAN, this wireless access point offers a

wireless interface and eliminates your effort busying cabling form one

computer to another.

With being compliant to IEEE 802.11g specification, this wireless

access point supports data rate up to 54Mbps and hence help to

construct your high-speed home or office wireless network. 802.11g is

also backward compatible with IEEE 802.11b wireless devices.

This access point equips one LAN port and one embedding antenna.

With supporting DHCP server and client, the W430 is easy to install and

setup. The wireless security mechanism is provided over 64/128-bit

WEP, WPA (TKIP with IEEE 802.1x), WPA2 and AES.

This device supports WEB-based graphics user interface that helps

users to configure this device easily.

Key Features

n Complies with IEEE 802.11b/g wireless standards

n Provides one 802.11b/g wireless Reverse SMA detachable antenna

n High speed transfer data rate up to 54Mbps

n Supports turbo mode for 72Mbps data transfer

n Supports wireless data encryption with 64/128-bit WEP, WPA (TKIP with

IEEE 802.1x), WPA2 and AES functions

n Supports one switch for selecting AP client mode or AP mode

n Supports Ad Hoc mode, Infrastructure mode, AP Bridge mode, AP Bridge

WDS mode and Repeater mode

n Supports authentication for wireless connectivity based on ESSID

n Provides MAC access control and hidden SSID function

n WDS supported with WEP, TKIP and AES encryption

n Supports DHCP server

n Supports firmware upgrade function via Web

n Compliant with FCC Part 15.247 for US, ETS 300 328 for Europe

n Flash: 2MB, SDRAM : 8MB

n Certifications: FCC Class B, CE Mark
