XAV101 Powerline AV Ethernet Adapter User Guide
Using the XAV101 Configuration Utility 2-5
v2.0, January 2009
1. Go to the XAV101 program group and select the Upgrade Tool.
2. Click Next to proceed.
The Upgrade Tool finds the adapter.
3. Follow the screen prompts to proceed with the upgrade.
4. At the end, click Finish when done. Repeat this process to upgrade all the adapters in your
network.
Figure 2-5
Figure 2-6
Note: If the firmware on the attached adapter is already up-to-date, the Upgrade Tool
will notify you accordingly.
