XAVP1000 Adapter LEDs and Buttons
Item Description
Power
LED
• Solid green. The electrical power is on.
• Blinking green.The adapter is restarting or setting up
security.
• Amber. Power saving mode.
• Off. There is no electrical power.
Powerline
LED
• Solid. The adapter is connected to a Powerline network.
• Blinking. The adapter is sending or receiving data.
• Off. The adapter has not found any other compatible
Powerline devices using the same encryption key.
The Pick A Plug feature lets you pick the electrical outlet with
the strongest link rate, indicated by the color displayed by
the LED:
Green:
Link rate > 80
Mbps (Best)
Amber:
Link rate > 50 and
< 80 Mbps (Better)
Red:
Link rate < 50
Mbps (Good)
