ProSafe Wireless-N Access Point WNAP210 Reference Manual
Advanced Configuration 4-9
v1.0 March 2009
When you click the Edit button, you must enter the profile name and the MAC address
(physical address) of the other bridge-mode wireless station in the fields provided. WEP,
WPA-PSK, or WPA2-PSK are supported. WPA2-PSK can (and should) be used to protect this
communication.
• W
ireless Point-to-Multi-Point Bridge. Select this only if this WNAP210 access point is the
master for a group of bridge-mode wireless stations. This mode supports default association
with wireless clients. To associate wireless clients with this Access Point, choose clients from
the list in the Enable Wireless Clients Association table, and select the corresponding check
box in the Enable column.
The other bridge-mode wireless stations must be set to point-t
o-point bridge mode, using the
MAC address of this WNAP210 access point. They then send all traffic to this master, rather
than communicate directly with each other.
When you click the Edit button, you must enter the
profile name and the MAC address
(physical address) of the other bridge-mode wireless stations in the fields provided. WEP,
WPA-PSK, or WPA2-PSK are supported. WPA2-PSK can (and should) be used to protect this
communication.
These features are accessed by selecting Configuration
> Wireless Bridge (see Figure 4-5
below).
• Repeater. If
this option is selected, this wireless access point will operate as a repeater only,
and send all traffic to the remote access point.
Note: This option does not support communication with wireless clients, that is, the
client cannot associate with the access point when it is operating as a repeater.
When you click the Edit button, you must enter the profile name and the MAC address
(physical address) of the other bridge-mode wireless station in the fields provided. WEP,
WPA-PSK, or WPA2-PSK are supported. WPA2-PSK can (and should) be used to protect this
communication.
• Client Mode. If selected, this wireless access point will
operate as a client bridge only, and
send all traffic to the remote access point or peer device. MAC Cloning can also be enabled in
Client Mode..
