Figure 3-12
ProSafe Wireless-N Access Point WNAP210 Reference Manual
3-14 Management
v1.0 March 2009
2. Click Refresh to update the statistics information for each interface. .
Table 3-2 describes the information fields detailed on the
Statistics screen.
Table 3-2. Statistics Fields
Field Description
Wired Ethernet
Packets The number of packets sent and received since the WNAP210 was
restarted.
Bytes The number of bytes sent and received since the WNAP210 was restarted.
Wireless 11n/g
Unicast Packets The unicast packets sent and received since the WNAP210 was restarted.
Broadcast Packets The broadcast packets sent and received since the WNAP210 was
restarted.
