Connect to the Network and Access the Router
16
Orbi High-Performance AC3000 Tri-band WiFi System
4. Within two minutes, on your WiFi-enabled computer or mobile device, press its WPS button
or follow its instructions for WPS connections.
Your computer or mobile device connects to the WiFi network.
Labels
The router label shows the login information, the WiFi network name and password, the
router’s MAC address, and the router’s serial number.
Figure 5. Router label
The label on the satellite shows the WiFi network name and password, the satellite’s MAC
address, and the satellite’s serial number.
Figure 6. Satellite label
Types of Logins
Separate types of logins serve different purposes. It is important that you understand the
difference so that you know which login to use when.
Types of logins:
• Internet service login.
The login that your Internet service provider (ISP) gave you logs
you in to your Internet service. Your service provider gave you this login information in a
letter or some other way. If you cannot find this login information, contact your service
provider.
