Supplemental Information
122
Orbi High-Performance AC3000 Tri-band WiFi System
Factory Settings
You can return the router or the satellite to its factory settings. Use the end of a paper clip or
a similar object to press and hold the Reset button on the back of the router or satellite for at
least seven seconds. The router or satellite resets, and returns to the factory settings.
The following table shows the factory default settings for the router.
Table 4. Factory default settings for the router
Feature Default Setting
Router login User login URL orbilogin.com
User name (case-sensitive) admin
Login password (case-sensitive) password
Internet
connection
WAN MAC address Use default hardware address
WAN MTU size 1500
Port speed AutoSensing
Local network
(LAN)
LAN IP 192.168.1.1
Subnet mask 255.255.255.0
DHCP server Enabled
DHCP range 192.168.1.2 to 192.168.1.254
DHCP starting IP address 192.168.1.2
DHCP ending IP address 192.168.1.254
DMZ Disabled
Time zone GMT for WW except NA and GR, GMT+1 for GR, GMT-8
for NA
Time zone adjusted for daylight
saving time
Disabled
SNMP Disabled
Firewall Inbound (communications coming
in from the Internet)
Disabled (except traffic on port 80, the HTTP port)
Outbound (communications going
out to the Internet)
Enabled (all)
Source MAC filtering Disabled
