Manage Your Network
99
Nighthawk X4 AC2350 Smart WiFi Router
Update the Router Firmware
The router firmware (routing software) is stored in flash memory. You might see a message
at the top of the genie screens when new firmware is available. You can respond to that
message to update the firmware or you can check to see if new firmware is available and
update your product.
To check for new firmware and update your router:
1. Launch a web browser from a computer or wireless device that is connected to the
network.
2. Type http://www.routerlogin.net or http://www.routerlogin.com.
A login screen displays.
3. Enter the router user name and password.
The user name is admin. The default password is password. The user name and
password are case-sensitive.
The BASIC Home screen displays.
4. Select ADVANCED > Administration > Firmware Update.
The Router Update screen displays.
5. Click the Check button.
The router finds new firmware information if any is available and displays a message
asking if you want to download and install it.
6. Click the Yes button.
The router locates and downloads the firmware and begins the update.
WARNING:
To avoid the risk of corrupting the firmware, do not interrupt the
upgrade. For example, do not close the browser, click a link, or load
a new page. Do not turn off the router.
When the upload is complete, your router restarts. The upgrade process typically takes
about one minute. Read the new firmware release notes to find out if you need to
reconfigure the router after upgrading.
