Supplemental Information
170
Nighthawk X4 AC2350 Smart WiFi Router
Technical Specifications
Table 4. R7500 router specifications
Feature Description
Data and routing protocols TCP/IP, RIP-1, RIP-2, DHCP, PPPoE, PPTP, Bigpond, Dynamic DNS, UPnP,
and SMB
Power adapter • North America:
100~240V, 50/60 Hz input
• UK, Australia:
100~240V, 50/60 Hz, input
• Europe: 100~240V
, 50/60 Hz input
• All regions (output): 12V/3.5A DC output
Dimensions 11.22 x 7.26 x 1.97 in. (285 x 184.5 x 50 mm)
Weight 1.65 lb (750 g)
Operating temperature 0° to 40°C (32º to 104ºF)
Operating humidity 90% maximum relative humidity, noncondensing
Electromagnetic emissions FCC Part 15 Class B
VCCI Class B
EN 55 022 (CISPR 22), Class B C-Tick N10947
LAN 10BASE-T or 100BASE-TX or 1000BASE-T, RJ-45
WAN 10BASE-T or 100BASE-TX or 1000BASE-T, RJ-45
Wireless Maximum wireless signal rate complies with the IEEE 802.11 standard.
*
*. Maximum wireless signal rate derived from IEEE Standard 802.11 specifications. Actual throughput can vary. Network
conditions and environmental factors, including volume of network traffic, building materials and construction, and network
overhead, lower actual data throughput rate.
Radio data rates Auto Rate Sensing
Data encoding standards • IEEE® 802.1
1 b/g/n 2.4 GHz–256 QAM support
• IEEE® 802.1
1 a/n/ac 5.0 GHz
Maximum computers per
wireless network
Limited by the amount of wireless network traffic generated by each node
(typically 50–70 nodes).
Operating frequency range AC2350
†
†. NETGEAR makes no express or implied representations or warranties about this product’s compatibility with any future
standards. 802.11ac 1733 Mbps is approximately 4x faster than 802.11n 450 Mbps. 2.4 GHz Performance Mode requires 256
QAM support on the WiFi client. Up to 1733 Mbps wireless speeds achieved when connecting to other 802.11ac 1733 Mbps
devices.
WiFi
• 600 Mbps @2.4GHz–256 QAM
• 1733 Mbps @5 GHz 1
1ac
802.11 security WPA2-PSK and WPA/WPA2
