Specify Internet Port Settings
153
Nighthawk X4 AC2350 Smart WiFi Router
5. Your router performs Network Address Translation (NAT) on the source IP address and
sends the reply through the Internet to the computer or wireless device that sent the web
page request.
Set Up Port Triggering
Port triggering is a dynamic extension of port forwarding that is useful in these cases:
• An application must use port forwarding to more than one local computer (but not
simultaneously).
• An application must open incoming ports that are different from the outgoing port.
With port triggering, the router monitors traffic to the Internet from an outbound “trigger” port
that you specify. For outbound traffic from that port, the router saves the IP address of the
computer that sent the traffic. The router temporarily opens the incoming port or ports that
you specify in your rule and forwards that incoming traffic to that destination.
Port forwarding creates a static mapping of a port number or range of ports to a single local
computer. Port triggering can dynamically open ports to any computer when needed and
close the ports when they are no longer needed.
Note: If you use applications such as multiplayer gaming, peer-to-peer
connections, real-time communications such as instant messaging, or
remote assistance (a feature in Windows XP), enable Universal Plug
and Play (UPnP). See
Improve Network Connections with Universal
Plug and Play on page 45.
Add a Port Triggering Service
To add a port triggering service:
1. Launch a web browser from a computer or wireless device that is connected to the
network.
2. Type http://www.routerlogin.net or http://www.routerlogin.com.
A login screen displays.
3. Enter the router user name and password.
The user name is admin. The default password is password. The user name and
password are case-sensitive.
The BASIC Home screen displays.
4. Select ADVANCED > Advanced Setup > Port Forwarding/Port Triggering.
The Port Forwarding/Port Triggering screen displays.
5. Select the Port Triggering radio button.
