User's Manual

ProSecure Web/Email Security Threat Management (STM) Appliance Reference Manual
2-8 Using the Setup Wizard to Provision the STM in Your Network
v1.0, September 2009
Understanding the Web Management Interface Menu Layout
Figure 2-7 shows the menu at the top of the STM600’s Web Management Interface. The Web
Management Interface layouts of the STM150 and STM300 are identical.
The Web Management Interface menu consists of the following components:
• 1st Level: Main navigation menu links. The main navigation menu in the orange bar across
the top of the Web Management Interface provide access to all the configuration functions of
the STM, and remain constant. When you select a main navigation menu link, the letters are
displayed in white against an orange background.
• 2nd Level: Configuration menu links. The configuration menu links in the gray bar
(immediately below the main navigation menu bar) change according to the main navigation
menu link that you select. When you select a configuration menu link, the letters are displayed
in white against a grey background.
• 3rd Level: Submenu tabs. Each configuration menu item has one or more submenu tabs that
are listed below the grey menu bar. When you select a submenu tab, the text is displayed in
white against a blue background.
The bottom of each screen provides action buttons. The nature of the screen determines which
action buttons are shown Figure 2-8 shows an example.
Figure 2-7
Figure 2-8
2nd Level: Configuration Menu Link (gray)
1st Level: Main Navigation Menu Link (orange)
3rd Level: Submenu Tab (blue)
