FS728TP Smart Switch Software Administration Manual
Managing System Settings 3-57
v1.1, September 2009
• Rx Frames – Indicates the total amount of LLDP packets received on the port, including:
–Total – Indicates the total amount of valid LLDP packets received on the port.
– Discarded – Indicates the total amount of LLDP packets that were discarded on the
port.
– Errors – Indicates the total amount of LLDP packets that were errors on the port.
• Rx TLVs – Indicates the total amount of Type Length Value received on the port,
including:
– Discarded – Indicates the total number of TLVs discarded on the port.
– Unrecognized – Indicates the total number of TLV which were not recognized by the
port.
• Rx Age-outs Total – Indicates the total amount of LLDP entries that were aged out on the
port.
2. Select a stacking member in the Unit No. field. The LLDP statistics for the stacking member
are displayed.
