• VID – Displays the protocol VLAN ID.
• Supported – Displays the supported Port and Protocol VLAN IDs.
• Enabled – Displays the Enabled Port and Protocol VLAN IDs.
VLAN IDs
• VID – Displays the Port and Protocol VLAN ID.
• VLAN Names – Displays the advertised VLAN names.
Protocol IDs
• Protocol ID – Displays the advertised protocol IDs.
MED Details
• Capabilities Supported – Displays the MED capabilities enabled on the port.
• Current Capabilities – Displays the MED TLVs advertised by the port.
• Device Class – Displays the LLDP-MED endpoint device class. The possible device
classes are:
– Endpoint Class 1 – Indicates a generic endpoint class, offering basic LLDP services.
– Endpoint Class 2 – Indicates a media endpoint class, offering media streaming
capabilities as well as all Class 1 features.
– Endpoint Class 3 – Indicates a communications device class, offering all Class 1 and
Class 2 features plus location, 911, Layer 2 switch support and device information
management capabilities.
• PoE Device Type – Displays the port PoE type. For example, Powered.
• PoE Power Source – Displays the port’s power source.
• PoE Power Priority – Displays the port’s power priority.
• PoE Power Value – Displays the port’s power value.
• Hardware Revision – Displays the hardware version.
• Firmware Revision – Displays the firmware version.
• Software Revision – Displays the software version.
• Serial Number – Displays the device serial number.
• Manufacturer Name – Displays the device manufacturer name.
• Model Name – Displays the device model name.
