– False – Indicates Auto-negotiation is not supported on the port.
• Auto-Negotiation Enabled – Displays the port speed auto-negotiation active status. The
possible values are:
– True – Indicates Auto-negotiation is enabled on the port.
– False – Indicates Auto-negotiation is not enabled on the port.
• Auto-Negotiation Advertised Capabilities – Displays the port speed auto-negotiation
capabilities. For example, 1000BASE-T half duplex mode, 100BASE-TX full duplex
mode.
• Operational MAU Type – Displays the Medium Attachment Unit (MAU) type. The
MAU performs physical layer functions, including digital data conversion from the
Ethernet interfaces’ collision detection and bit injection into the network. For example,
100BASE-TX full duplex mode.
802.3 Power via MDI
• MDI Power Support Port Class – Displays the advertised power support port class.
• PSE MDI Power Support – Indicates if MDI power is supported on the port.
• PSE MDI Power State – Indicates if MDI power is enabled on the port.
• PSE Power Pair Control Ability – Indicates if power pair control is supported on the
port.
• PSE Power Pair – Displays the power pair control type supported on the port.
• PSE Power Class – Displays the advertised power class of the port.
802.3 Link Aggregation
• Aggregation capability – Indicates if the port can be aggregated.
• Aggregation status – Indicates if the port is currently aggregated.
• Aggregation Port ID – Displays the advertised aggregated port ID.
802.3 Details
• 802.3 Maximum Frame Size – Displays the advertised maximum frame size that is
supported on the port.
802.1 VLAN and Protocol
• PVID – Displays the advertised port VLAN ID.
PPVIDs
